Specifications
FA Series Batch High Shear Dispersing Emulsifier
| Model | Rated power (kW) | Max. speed (rpm) | Max. processing capacity (L), H₂O |
| FA/FAB/FAS60 | 0.75 | 6000 | 30 |
| FA/FAB/FAS90 | 1.5 | 3000 | 50 |
| FA/FAB/FAS100 | 2.2 | 3000 | 100 |
| FA/FAB/FAS120 | 4 | 3000 | 300 |
| FA/FAB/FAS140 | 7.5 | 3000 | 800 |
| FA/FAB/FAS160 | 11 | 3000 | 1000 |
| FA/FAB/FAS180 | 18.5 | 1500 | 1500 |
| FA/FAB/FAS220 | 30 | 1500 | 2500 |
| FA/FAB/FAS240 | 37 | 1500 | 4000 |
| FA/FAB/FAS270 | 55 | 1500 | 6000 |
FM Series Batch High Shear Dispersing Emulsifier
| Model | Rated power (kW) | Max. speed (rpm) | Max. processing capacity (L), H₂O |
| FM/FMB/FMS60 | 0.75 | 6000 | 30 |
| FM/FMB/FMS90 | 1.5 | 3000 | 50 |
| FM/FMB/FMS100 | 2.2 | 3000 | 100 |
| FM/FMB/FMS120 | 4 | 3000 | 300 |
| FM/FMB/FMS140 | 7.5 | 3000 | 800 |
| FM/FMB/FMS160 | 11 | 3000 | 1000 |
| FM/FMB/FMS180 | 18.5 | 1500 | 1500 |
| FM/FMB/FMS220 | 30 | 1500 | 2500 |
| FM/FMB/FMS240 | 37 | 1500 | 4000 |
| FM/FMB/FMS270 | 55 | 1500 | 6000 |
FU Series Batch High Shear Dispersing Emulsifier
| Model | Rated power (kW) | Max. speed (rpm) | Max. processing capacity (L), H₂O |
| FU/FUB/FUS90 | 1.5 | 3000 | 100 |
| FU/FUB/FUS100 | 2.2 | 3000 | 300 |
| FU/FUB/FUS120 | 5.5 | 3000 | 700 |
| FU/FUB/FUS140 | 7.5 | 1500 | 1500 |
| FM/FMB/FMS180 | 18.5 | 1500 | 2500 |
| FU/FUB/FUS220 | 30 | 1500 | 3500 |
Working Principle
This dispersing emulsifier features an innovative design with a compact structure, utilizing a high-density die-cast aluminum alloy housing and a micro-motor that offers high power and speed with reliable operation. The controller employs digital control technology, providing easy data collection and displaying operational status. The stainless-steel homogenizing and dispersing head used in this emulsifier offers excellent corrosion resistance.
Applications
Suitable for various processes such as material breaking, dispersion, emulsification, homogenization, and mixing under standard operating conditions.
Features
Customized solutions can be provided to accommodate different container shapes and customer requirements.
